AVO830
Digital TRMS multimeter
The AVO835 is no longer available
- TRMS voltage and current measurement
- Dual digital readout
- Classic Megger analogue arc
- 0.1% basic accuracy
- Phase sequence measurement for 3 phase circuit and motor testing
- 10 MΩ and 10 kΩ input impedance switching
- Non-contact live circuit detection with Hi/low sensitivity
- Resistance from 0.01 Ω to 50 MΩ, conductance and Diode measurement
- Official Megger supplier
- Delivered at 30+ Indian ports
- Quote within 24 hours
Overview
Megger AVO830 digital TRMS multimeter has been designed for professional electricians, technicians, service personnel, and engineers that require high reliability, build quality, and performance in a compact, tough, weatherproof case.
The AVO830 is a true RMS multimeter with up to 600 V AC, DC, and AC+DC voltage measurement ranges and current measurements from 0.1 mA to 10 A.
- Auto and manual range control
- Minimum, maximum and average measurement capture
- Measurement smoothing for fast changing quantity capture
- Hold and Auto Hold modes
- 800 Hz Low pass filter
- Capacitance and frequency measurement
- Temperature measurement*
- IP54 environmental protection
Specifications
- Current measuring range (AC)
- 0.1 mA - 10 A
- Current measuring range (DC)
- 0.1 mA - 10 A
- Electrical measurement category
- CAT IV 600 V
- Max resistance reading
- 50MΩ
